Volvo Penta Propeller | 110-250hp Short Hub
Make: Volvo Penta
Horsepower: 110, 250hp
Years: All
Blades: 3
(not thru hub exhaust)
Short hub
Highest quality boat propellers designed and manufactured in the USA
View prop codes, specifications & applications below, or...
Couldn't load pickup availability
Volvo Penta Propeller Specifications
|
AL = Aluminum SS = Stainless Steel |
LL = Light Load HL = Heavy Load C = Cruise |
W = Weedless SW = Semi Weedless |
SP = Special Performance * = Cupped Propeller |
| Engine HP | Year/ Model |
Application | Material | Prop Size | No. Blades | Propco Code | Nearest OEM Equivalent Part No. |
| 110, 250hp short hub (not thru hub exhaust) Left Hand Rotation |
All models | HL | AL | 15 x 15 | 3 | VL215 | 814611 |
| C | AL | 14 3/4 x 17 | 3 | VL217 | 814627 | ||
| C | AL | 14 1/2 x 19 | 3 | VL219 | 814628 | ||
| LL | AL | 14 x 21 | 3 | VL221SP* | 814629 | ||
|
110, 250hp short hub (not thru hub exhaust) Right Hand Rotation |
All models | HL | AL | 15 x 15 | 3 | VR215 | 814615 |
| C | AL | 14 3/4 x 17 | 3 | VR217 | 814632 | ||
| C | AL | 14 1/2 x 19 | 3 | VR219 | 814633 | ||
| LL | AL | 14 x 21 | 3 | VR221SP* | 814634 |
| Engine HP | Year/ Model |
Application | Material | Prop Size | No. Blades | Propco Code | Nearest OEM Equivalent Part No. |
| 275, 280, 290hp long hub (not thru hub exhaust) Left Hand Rotation |
All models | HL | AL | 15 1/2 x 15 | 3 | VLL215 | 851037-2 |
| C | AL | 15 x 17 | 3 | VLL217 | 851124-8 | ||
| C | AL | 15 x 19 | 3 | VLL219 | 850864-0 | ||
| LL | AL | 15 x 21 | 3 | VLL221SP* | 850866-5 | ||
| HL | AL | 16 x 9 | 3 | VLL209 | Houseboat | ||
|
275, 280, 290hp long hub (not thru hub exhaust) Right Hand Rotation |
All models | HL | AL | 15 1/2 x 15 | 3 | VRL215 | 851038-0 |
| C | AL | 15 x 17 | 3 | VRL217 | 851125-5 | ||
| C | AL | 15 x 19 | 3 | VRL219 | 850865-7 | ||
| LL | AL | 15 x 21 | 3 | VRL221SP* | 850768-3 |
| Engine HP | Year/ Model |
Application | Material | Prop Size | No. Blades | Propco Code | Nearest OEM Equivalent Part No. |
|
Volvo SX Series 150-350hp |
93 thru | HL | AL | 16 x 10 | 3 | SXJR210SP* | |
| HL | AL | 15 3/4 x 13 | 3 | SXJR213SP* | |||
| HL | AL | 15 3/4 x 15 | 3 | SXJR215SP* | |||
| C | AL | 14 1/2 x 17 | 3 | SXJR217SP* | |||
| C | AL | 14 1/2 x 19 | 3 | SXJR219SP* | |||
| C | AL | 14 x 21 | 3 | SXJR221SP* | |||
| LL | AL | 14 x 23 | 3 | SXJR223SP* | |||
| LL | AL | 14 x 25 | 3 | SXJR225SP* | |||
| HL | SS | 14 1/4 x 15 | 3 | SXSSJR215SP* | Stainless Steel | ||
| C | SS | 14 1/4 x 17 | 3 | SXSSJR217SP* | Stainless Steel | ||
| C | SS | 14 1/4 x 19 | 3 | SXSSJR219SP* | Stainless Steel | ||
| LL | SS | 14 1/4 x 21 | 3 | SXSSJR221SP* | Stainless Steel | ||
| LL | SS | 14 1/4 x 23 | 3 | SXSSJR223SP* | Stainless Steel | ||
| LL | SS | 14 1/4 x 25 | 3 | SXSSJR225SP* | Stainless Steel | ||
|
Volvo SX Series 150-350hp (thru hub exhaust) 19 tooth spline Left Hand Rotation |
93 thru | C | AL | 14 1/2 x 17 | 3 | SXJL217SP* | |
| C | AL | 14 1/2 x 19 | 3 | SXJL219SP* | |||
| C | AL | 14 x 21 | 3 | SXJL221SP* | |||
| C | AL | 14 x 23 | 3 | SXJL223SP* | |||
| LL | AL | 14 x 25 | 3 | SXJL225SP* | |||
| HL | SS | 14 1/4 x 15 | 3 | SXSSJL215SP* | Stainless Steel | ||
| C | SS | 14 1/4 x 17 | 3 | SXSSJL217SP* | Stainless Steel | ||
| C | SS | 14 1/4 x 19 | 3 | SXSSJL219SP* | Stainless Steel | ||
| LL | SS | 14 1/4 x 21 | 3 | SXSSJL221SP* | Stainless Steel | ||
| LL | SS | 14 1/4 x 23 | 3 | SXSSJL223SP* | Stainless Steel | ||
| LL | SS | 14 1/4 x 25 | 3 | SXSSJL225SP* | Stainless Steel |
| Engine HP | Year/ Model |
Application | Material | Prop Size | No. Blades | Propco Code | Nearest OEM Equivalent Part No. |
|
Volvo SX Series 150-350hp |
93 thru | C | AL | 14 x 17 | 4 | SXQRJ-T J217SP* | Quad-R-Jet |
| C | AL | 14 x 19 | 4 | SXQRJ-T J219SP* | Quad-R-Jet |
||
| LL | AL | 14 x 21 | 4 | SXQRJ-T J221SP* | Quad-R-Jet | ||
| LL | AL | 14 x 23 | 4 | SXQRJ-T J223SP | Quad-R-Jet |
NOTE: If using Uncupped Propeller, use Cupped Propeller with 2" less pitch. Boats with power trim may use same pitch.
QRJ-T 4-blade gives better holeshot, less torque on steering, better boat handling and lower planing speeds.
|
AL = Aluminum SS = Stainless Steel |
LL = Light Load HL = Heavy Load C = Cruise |
W = Weedless SW = Semi Weedless |
SP = Special Performance * = Cupped Propeller |
REVERSE HOOK CUP PROPELLERS
Propco's patented Reverse Hook Cup Propellers are designed for use on houseboats, workboats and barges. 'RHC' technology gives up to 200% more reversibility - allowing drivers to turn more effectively, stop forward momentum, and control the boat while in reverse. Customers have stated the RHC propeller literally "takes the fear out of returning to the marina" and with this prop "the stern will now swing around and hold into the wind".
| Engine HP | Year/ Model |
Application | Material | Prop Size | No. Blades | Propco Code | Nearest OEM Equivalent Part No. |
| Volvo SX Drive 115-500hp Right Hand |
16 x 9 | RHCJR209SP | |||||
| 16 x 10 | RHCSXJR210SP | ||||||
| 16 x 11 | RHCSXJR211SP | ||||||
| 15 3/4 x 13 | RHCSXJR213SP | ||||||
| 16 x 14 | RHCSXJR214SP | ||||||
| 15 3/4 x 15 | RHCSXJR215SP | ||||||
| Volvo SX Drive 115-500hp Left Hand |
16 x 9 | RHCSXJL209SP | |||||
| 16 x 10 | RHCSXJL210SP | ||||||
| 16 x 11 | RHCSXJL211SP | ||||||
| 15 3/4 x 13 | RHCSXJL213SP | ||||||
| 15 3/4 x 15 | RHCSXJL215SP | ||||||
| Volvo Short Hub | 16 x 9 | RHCVL209 | |||||
| 15 x 15 | RHCVL215 | ||||||
| Volvo Long Hub | 15 1/2 x 13 | RHCVRL213 |
SPECIFICATIONS & FEATURES
-
Material
AL = Aluminum
SS = Stainless Steel
Dimensions are Diameter x Pitch -
Application
LL = Light Load
HL = Heavy Load
C = Cruise
HB = Houseboat/Pontoon -
Features
W = Weedless
SW = Semi Weedless
4 = 4-blades
SP = Special Performance
* = Cupped Propeller
QRJ = Quad-R-Jet
RH/LH = Right/Left Hand Rotation
